| Display |
|
| |
|
Viewing Angle
|
178°(H)/178°(V)
|
Contrast Ratio
|
3000:1
|
Screen Size
|
21.5 inch
|
Active Display Area
|
478.656 mm(H) × 260.28 mm (V)
|
Backlight
|
ELED
|
Pixel Pitch
|
0.24795 (H) mm × 0.24795 (V) mm
|
Resolution
|
1920 × 1080@60 Hz
|
Brightness
|
250 cd/m²
|
Color Depth
|
8 bit, 16.7 M
|
Response Time
|
6.5 ms
|
Color Gamut
|
72% NTSC
|
Reliability
|
7 × 24 h
|
Refresh Rate
|
60 Hz
|
| |
|
| |
|
| |
|
| Built-In System |
|
| |
|
Operation System
|
Android 8.1.0
|
CPU
|
Cortex-A17, 4-core, main frequency 1.6 GHZ
|
Memory
|
2 GB
|
Built-In Storage
|
16 GB
|
| |
|
| |
|
| |
|
| Interface |
|
| |
|
Video & Audio Input
|
AUDIO IN × 1
|
Video & Audio Output
|
AUDIO OUT × 1
|
Network Interface
|
LAN × 1, Wi-Fi
|
Data Transmission Interface
|
USB 2.0 × 2, TF Card × 1, BT4.0 × 2, Wi-Fi
|
| |
|
| |
|
| |
|
| Internal Function |
|
| |
|
Loudspeaker
|
2 × built-in speaker, 8 Ω 5 W
|
| |
|
| |
|
| |
|
| Power |
|
| |
|
Standby Consumption
|
≤ 10 W
|
Input Voltage
|
100 to 240 VAC, 50/60 ± 3 Hz
|
Power Consumption
|
≤ 40 W
|
| |
|
| |
|
| |
|
| Working Environment |
|
| |
|
Working Temperature
|
0 °C to 40 °C (32 °F to 104 °F)
|
Working Humidity
|
20% to 90% RH
|
Storage Temperature
|
-20 °C to 60 °C (-4 °F to 140 °F)
|
Storage Humidity
|
5% to 90% RH
|
| |
|
| |
|
| |
|
| General |
|
| |
|
Material Type
|
DAT, MPG, VOB, TS, AVI, MKV, MP4, MOV, 3GP, TS, FLV, WEBM, ASF, MP1, MP2, MP3, WMA, WAV, OGG, OGA, FLAC, ACC, M4A, XMF, MXMF, RTTTL, RTX, OTA, IMY, JPG, JPEG, BMP, GIF, PNG
|
Mounting Type
|
Wall-Mounted
|
Product Dimensions (W × H × D)
|
516.75 (W) × 320.03 (H) × 46.55 (D) mm (without wall-mounted backboard) (20.34'' × 12.60'' × 1.83'') 516.75 (W) × 320.03 (H) × 53.55 (D) mm (with wall-mounted backboard) (20.34'' × 12.60'' × 2.11'')
|
Package Dimensions (W × H × D)
|
593 (W) × 434 (H) × 157 (D) mm (23.35'' × 17.09'' × 6.18'')
|
Net Weight
|
3.03 Kg (6.68 lb)
|
Gross Weight
|
4.63 Kg (10.21 lb)
|
Packing List
|
Wall-mounted backboard × 1, screws M3 × 6, power cord × 1, remote control × 1, battery × 2, screw package × 1
|
