| Display |
|
| |
|
Screen Size
|
32 inch
|
Resolution
|
1920 × 1080
|
Active Display Area
|
698.4 (H) mm × 392.85 (V) mm
|
Pixel Pitch
|
0.36375 (H) mm × 0.36375 (V) mm
|
Backlight
|
E-LED
|
Viewing Angle
|
178°(H)/178°(V)
|
Brightness
|
350 cd/m²
|
Contrast Ratio
|
4000:1
|
Color Depth
|
8 bit, 16.7M
|
Response Time
|
6.5 ms
|
Color Gamut
|
72% NTSC
|
Reliability
|
7 × 24 h
|
Refresh Rate
|
60 Hz
|
| |
|
| |
|
| |
|
| Built-In System |
|
| |
|
Operation System
|
Android 8.1
|
Processor
|
Cortex-A17, 4-core, main frequency 1.6 GHz
|
Memory
|
2 GB
|
Built-In Storage
|
16 GB EMMC
|
| |
|
| |
|
| |
|
| Interface |
|
| |
|
Video & Audio Input
|
AUDIO IN × 1, HDMI × 2, VGA × 1
|
Video & Audio Output
|
AUDIO OUT × 1, speaker (8 Ω 2 W) × 2
|
Network Interface
|
LAN × 1, Wi-Fi × 1
|
Data Transmission Interface
|
USB 2.0 × 2, TF Card × 1, BT 4.0 × 1
|
| |
|
| |
|
| |
|
| Power |
|
| |
|
Standby Consumption
|
≤ 0.5 W
|
Input Voltage
|
100 to 240 VAC, 50/60 Hz
|
Power Consumption
|
≤ 75 W
|
| |
|
| |
|
| |
|
| Working Environment |
|
| |
|
Working Temperature
|
0 °C to 40 °C (32 °F to 104 °F)
|
Working Humidity
|
10% to 80% RH
|
Storage Temperature
|
-20 °C to 60 °C (-4 °F to 140 °F)
|
Storage Humidity
|
10% to 80% RH
|
| |
|
| |
|
| |
|
| General |
|
| |
|
Material Type
|
DAT, MPG, VOB, TS, AVI, MKV, MP4, MOV, 3GP, TS, FLV, WEBM, ASF, MP1, MP2, MP3, WMA, WAV, OGG, OGA, FLAC, ACC, M4A, XMF, MXMF, RTTTL, RTX, OTA, IMY, JPG, JPEG, BMP, GIF, PNG
|
Mounting Type
|
Wall mounting (horizontally or vertically)
|
Product Dimensions (W × H × D)
|
723.24 mm × 423.25 mm × 61.5 mm (with wall-mounted backboard) (28.47'' × 16.66'' × 2.42'') 723.24 mm × 423.25 mm × 45.13 mm (without wall-mounted backboard) (28.47'' × 16.66'' × 1.78'')
|
Package Dimensions (W × H × D)
|
898 mm × 152 mm × 544 mm (35.35'' × 5.98'' × 21.42'')
|
Net Weight
|
5.90 kg (13.01 lb.)
|
Gross Weight
|
9.13 kg (20.13 lb.)
|
Packing List
|
Digital signage × 1, power cord × 1, remote control × 1, wall-mounted backboard × 1, package of mounting bolts × 1, wall-mounted screw × 4, desiccative × 1, quick start guide × 1
|
