| Display |
|
| |
|
Screen Size
|
55 inch
|
Resolution
|
3840 × 2160
|
Active Display Area
|
1209.6 (H) mm × 680.4 (V) mm
|
Pixel Pitch
|
0.315 (H) mm × 0.315 (V) mm
|
Backlight
|
D-LED
|
Viewing Angle
|
178° (H) /178° (V)
|
Brightness
|
500 cd/m²
|
Contrast Ratio
|
4000:1
|
Color Depth
|
10 bit, 1.07B
|
Response Time
|
8 ms
|
Color Gamut
|
72% NTSC
|
Reliability
|
7 × 24 h
|
Refresh Rate
|
60 Hz
|
| |
|
| |
|
| |
|
| Built-In System |
|
| |
|
Operation System
|
Android 8.1
|
Processor
|
Cortex-A17, 4-core, main frequency 1.6 GHz
|
Memory
|
2 GB
|
Built-In Storage
|
16 GB EMMC
|
| |
|
| |
|
| |
|
| Interface |
|
| |
|
Video & Audio Input
|
AUDIO IN × 1, HDMI × 2, VGA × 1
|
Video & Audio Output
|
AUDIO OUT × 1, speaker (8 Ω 5 W) × 2
|
Network Interface
|
LAN × 1,Wi-Fi × 1
|
Data Transmission Interface
|
USB 2.0 × 2, TF Card × 1, BT 4.0 × 1
|
| |
|
| |
|
| |
|
| Power |
|
| |
|
Standby Consumption
|
≤ 0.5 W
|
Input Voltage
|
100 to 240 VAC, 50/60 Hz
|
Power Consumption
|
≤ 200 W
|
| |
|
| |
|
| |
|
| Working Environment |
|
| |
|
Working Temperature
|
0 °C to 40 °C (32 °F to 104 °F)
|
Working Humidity
|
10% to 80% RH
|
Storage Temperature
|
-20 °C to 60 °C (-4 °F to 104 °F)
|
Storage Humidity
|
5% to 90% RH
|
| |
|
| |
|
| |
|
| General |
|
| |
|
Material Type
|
DAT, MPG, VOB, TS, AVI, MKV, MP4, MOV, 3GP, TS, FLV, WEBM, ASF, MP1, MP2, MP3, WMA, WAV, OGG, OGA, FLAC, ACC, M4A, XMF, MXMF, RTTTL, RTX, OTA, IMY, JPG, JPEG, BMP, GIF, PNG
|
Mounting Type
|
Wall mounting (horizontally or vertically)
|
Product Dimensions (W × H × D)
|
1237.2 mm × 708 mm × 83.44 mm (without wall-mounted backboard) (48.71'' × 27.87'' × 3.29'') 1237.2 mm × 708 mm × 102.44 mm (with wall-mounted backboard) (48.71'' × 27.87'' × 4.03'')
|
Package Dimensions (W × H × D)
|
1403 mm × 856 mm × 217 mm (55.24'' × 33.70'' × 8.54'')
|
Net Weight
|
19.2 kg (42.33 lb.)
|
Gross Weight
|
24.53 kg (54.08 lb.)
|
Packing List
|
Digital signage × 1, power cord × 1, remote control × 1, wall-mounted backboard × 1, package of mounting bolts × 1, wall-mounted screw × 4, desiccative × 1, quick start guide × 1
|
