| PANEL |
|
| Screen Size |
43" |
| Resolution |
1,920 x 1,080 (FHD) |
| Brightness(Typ.,cd/m?) |
450 |
CONNECTIVITY
|
|
| Input |
HDMI (3), DP, DVI-D, Audio, USB 3.0 |
| Output |
DP(SST), Audio(Off/Fixed/Variable) |
| External Control |
RS232C In/Out, RJ45 In, IR Receiver In |
PHYSICAL SPECIFICATION
|
|
| Bezel Width |
11.9 mm (T/R/L), 18 mm (B) |
| Monitor Dimension (W x H x D) |
969.6 x 563.9 x 54 mm |
| Weight (Head) |
10.0 kg |
| Monitor with Optional Stand Dimensions (W x H x D) |
969.6 x 622.2 x 193 mm |
| Weight (Head+Stand) |
12.5 kg |
| Carton Dimensions (W x H x D) |
1,052 x 650 x 123 mm |
| Packed Weight |
12.6 kg |
| VESA Standard Mount Interface |
200 x 200 mm |
ENVIRONMENT CONDITIONS
|
|
| Operation Temperature |
0°C to 40°C |
| Operation Humidity |
10 % to 80 % |
POWER
|
|
| Power Supply |
100-240 V~, 50/60 Hz |
| Power Type |
Built-In Power |
POWER CONSUMPTION
|
|
| Typ. / Max. |
75 W / 95 W |
| Smart Energy Saving |
55 W |
STANDARD(CERTIFICATION)
|
|
| Safety |
IEC 60950-1 / EN 60950-1 / UL 60950-1 |
| EMC |
FCC Class "A" / CE / KC |
| ErP / Energy Star |
Yes (EU Only) |
MEDIA PLAYER COMPATIBILITY
|
|
| OPS type compatible |
Yes |
| External Media player Attatchable |
Yes |
SOFTWARE COMPATIBILITY
|
|
| Content Management Software |
SuperSign CMS |
| Control and Monitoring Software |
SuperSign Control+/Control |
MINIMUM REQUIREMENTS FOR LG PRESENTER
|
|
| OS (Windows) |
Windows 7 (64bit), Windows 10 (64bit) |
| OS (macOS) |
macOS 10.12 Sierra, MacOS 10.13 High Sierra |
| CPU (Windows) |
2.7GHz+ Dual Core Broadwell or higher |
| CPU (macOS) |
Any CPU which supports Sierra or High Sierra |
| Memory |
4GB RAM |
| Hard Drive |
1GB of free space |
| Graphics Hardware (Windows) |
Intel Iris or higher, Nvidia, ATI |
| Graphics Hardware (macOS) |
Any GPU which supports Sierra or High Sierra |
ACCESSORY
|
|
| Basic |
Remote Controller (2ea batteries included), Power cord, QSG, HDMI cable, Regulation book, Phone to RS232C gender, Memory cover |
| Optional |
Stand (ST-432T), Media Player, Wall Bracket (LSW230B), VESA Adapter (AM-B220S), OPS Kit (KT-OPSF), Touch Overlay (KT-T43E) |
GENERAL
|
|
| Region |
Global |
