General |
|
|
|
Model name
|
272S1AE
|
EAN
|
8712581767273
|
|
|
|
|
|
|
Stand
|
|
|
|
Height adjustment
|
130
|
Tilt
|
-5~25
|
Pivot
|
-/+ 90 degree
|
Swivel
|
-/+ 180
|
|
|
|
|
|
|
What's in the box?
|
|
|
|
Cables
|
VGA cable, HDMI cable, DP cable, Audio cable, Power cable
|
Monitor with stand
|
Yes
|
User Documentation
|
Yes
|
|
|
|
|
|
|
Convenience
|
|
|
|
Built-in Speakers
|
2 W x 2
|
Control software
|
SmartControl
|
Plug and Play Compatibility
|
DDC/CI, Mac OS X, sRGB, Windows 10 / 8.1 / 8 / 7
|
Other convenience
|
Kensington lock, VESA mount (100 x 100 mm)
|
OSD Languages
|
Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian
|
User convenience
|
SmartImage, Input, Brightness, Menu, Power On/Off
|
|
|
|
|
|
|
Compliance and standards
|
|
|
|
Regulatory Approvals
|
CB, EPA, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, UKRAINIAN, CCC, CEL, CECP, TUV Eye Comfort certified
|
|
|
|
|
|
|
Cabinet
|
|
|
|
Front bezel
|
Black
|
Finish
|
Texture
|
Rear cover
|
Black
|
Foot
|
Black
|
|
|
|
|
|
|
Dimensions
|
|
|
|
Product with stand (max height)
|
613 x 537 x 205
|
Product without stand (mm)
|
613 x 366 x 51
|
Packaging in mm (W x H x D)
|
700 x 456 x 216
|
|
|
|
|
|
|
Operating conditions
|
|
|
|
Temperature range (operation)
|
0°C to 40°C
|
Temperature range (storage)
|
-20°C to 60°C
|
Relative humidity
|
20%-80
|
Altitude
|
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
|
MTBF (demonstrated)
|
70,000 hrs (excluded backlight)
|
|
|
|
|
|
|
Connectivity
|
|
|
|
Signal Input
|
VGA (Analogue), DVI-D (digital, HDCP), DisplayPort 1.2, HDMI 1.4
|
HDCP
|
HDCP 1.4 (DVI/DP/HDMI)
|
Audio (In/Out)
|
PC audio-in, Headphone out
|
Sync Input
|
Separate Sync, Sync on Green
|
|
|
|
|
|
|
Power
|
|
|
|
On mode
|
16.3 W (typ.) (Energy Star test method)
|
Standby mode
|
0.3 W (typ.)
|
Off mode
|
0.2 W (typ.)
|
Power LED indicator
|
Operation - White, Standby mode - White (flashing)
|
Power supply
|
Built-in, 100–240 VAC, 50–60 Hz
|
ECO mode
|
11.5 W (typ.)
|
Energy Label Class
|
E
|
|
|
|
|
|
|
Weight
|
|
|
|
Product with stand (kg)
|
6.00
|
Product without stand (kg)
|
4.13
|
Product with packaging (kg)
|
8.21
|
|
|
|
|
|
|
Sustainability
|
|
|
|
Environmental and energy
|
EnergyStar 8.0, EPEAT*, TCO Certified, RoHS
|
Recyclable packaging material
|
100
|
Specific Substances
|
PVC/BFR free housing, Mercury free
|
Post-consumer recycled plastic
|
85%
|
|
|
|
|
|
|
Picture/Display
|
|
|
|
Adaptive sync
|
Yes
|
Maximum resolution
|
1920 x 1080 @ 75 Hz*
|
EasyRead
|
Yes
|
Colour gamut (typical)
|
NTSC 81%*, sRGB 102%*
|
Brightness
|
250
|
Aspect ratio
|
16:9
|
Display Screen Coating
|
Anti-Glare, 3H, Haze 25%
|
Effective viewing area
|
597.888 (H) x 336.312 (V)
|
Panel Size
|
27 inch/68.6 cm
|
Backlight type
|
W-LED system
|
LCD panel type
|
IPS technology
|
SmartContrast
|
50,000,000:1
|
Contrast ratio (typical)
|
1000:1
|
Pixel pitch
|
0.3114 x 0.3114 mm
|
LowBlue Mode
|
Yes
|
Flicker-free
|
Yes
|
Pixel Density
|
82 PPI
|
Response time (typical)
|
4 ms (Grey to Grey)*
|
Picture enhancement
|
SmartImage
|
sRGB
|
Yes
|
Scanning Frequency
|
30–85 kHz (H) / 48–75 Hz (V)
|
Display colours
|
16.7 M
|
Viewing angle
|
178º (H)/178º (V), @ C/R > 10
|
