345B1C/00 |
|
B-sorozatú 34"-es (86,36 cm-es) ívelt UltraWide LCD képernyő |
|
|
|
A Philips B sorozatú, 34"-es ívelt UltraWide kijelző átfogóan jeleníti meg munkáját. Kristálytiszta WQHD kijelző és ergonomikus állvány gondoskodik az optimális munkakörülményekről. A szemek kényelmét szolgáló, TÜV tanúsítvánnyal rendelkező funkciók csökkentik a szemfáradást. |
|
|
|
|
Picture/Display
|
|
|
|
LowBlue Mode
|
Yes
|
Adaptive sync
|
Yes
|
Maximum resolution
|
3440 x 1440 @ 100 Hz*
|
SmartUniformity
|
93 ~ 105%
|
Delta E
|
< 2 (sRGB)
|
Colour gamut (typical)
|
NTSC 100%*, sRGB 119%*, Adobe RGB 90%*
|
Flicker-free
|
Yes
|
Response time (typical)
|
5 ms (Grey to Grey)*
|
LCD panel type
|
VA LCD
|
Panel Size
|
34 inch / 86.36 cm
|
Effective viewing area
|
797.2 (H) x 333.7 (V) — at a 1500 R curvature*
|
Aspect ratio
|
21:9
|
Brightness
|
300
|
Contrast ratio (typical)
|
3000:1
|
SmartContrast
|
80,000,000 :1
|
Pixel pitch
|
0.232 x 0.232 mm
|
Pixel Density
|
110 PPI
|
Display Screen Coating
|
Anti-Glare, 2H, Haze 25%
|
Backlight type
|
W-LED system
|
sRGB
|
Yes
|
Scanning Frequency
|
30–160 kHz (H)/48–100 Hz (V)
|
Display colours
|
16.7 M
|
Picture enhancement
|
SmartImage
|
Viewing angle
|
178º (H)/178º (V), @ C/R > 10
|
Blue Light Technology
|
Low Blue Mode
|
Productline
|
B-line
|
Resolution
|
3440x1440 PX
|
Contrast Static
|
3000:1
|
Refresh Rate
|
100Hz Hz
|
Display Colours
|
16.7 M
|
Sync Technology
|
Adaptive Sync
|
Diagonal CM
|
86.36 cm
|
Diagonal Inch
|
34 Inch
|
Panel
|
VA
|
Curved
|
1500R
|
Response Time
|
5
|
Brightness Max
|
300
|
Viewing angle (CR10)
|
178/178
|
Contrast (dynamic)
|
80m:1
|
|
|
|
|
|
|
Connectivity
|
|
|
|
HDCP
|
HDCP 1.4 (DP/USB-C), HDCP 2.2 (HDMI)
|
RJ45
|
Ethernet LAN (10 M/100 M/1 G)*
|
USB:
|
USB-C x 1, USB-B x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)
|
Signal Input
|
DisplayPort 1.2 x 1, HDMI 2.0 x 1, USB-C 3.2 Gen 1 x 1 (upstream, power delivery up to 90 W)
|
Audio (In/Out)
|
Headphone out
|
Sync Input
|
Separate Sync, Sync on Green
|
|
|
|
|
|
|
Convenience
|
|
|
|
Built-in Speakers
|
5 W x 2
|
Control software
|
SmartControl
|
Plug and Play Compatibility
|
DDC/CI, Mac OS X, sRGB, Windows 10 / 8.1 / 8 / 7
|
Other convenience
|
Kensington lock, VESA mount (100 x 100 mm)
|
User convenience
|
SmartImage, Input, User, Menu, Power On/Off
|
Height adjust amount
|
180 mm
|
Speakers
|
5 W x 2
|
Swivel
|
-180/180
|
Tilt
|
-5/30
|
|
|
|
|
|
|
Stand
|
|
|
|
Height adjustment
|
180
|
Swivel
|
-180/180
|
Tilt
|
-5/30
|
|
|
|
|
|
|
Power
|
|
|
|
ECO mode
|
34 W (typ.)
|
On mode
|
46.8 W (typ.) (EnergyStar 7.0 test method)
|
Standby mode
|
0.3 W (typ.)
|
Off mode
|
Zero watts with Zero switch
|
Power LED indicator
|
Operation - White, Standby mode - White (flashing)
|
Power supply
|
Built-in, 100–240 VAC, 50–60 Hz
|
Energy Label Class
|
B
|
Powersupply
|
Internal
|
|
|
|
|
|
|
Dimensions
|
|
|
|
Product without stand (mm)
|
807 x 367 x 110
|
Packaging in mm (W x H x D)
|
930 x 525 x 282
|
Product with stand (max height)
|
807 x 601 x 250
|
|
|
|
|
|
|
Weight
|
|
|
|
Product with stand (kg)
|
11.49
|
Product without stand (kg)
|
7.79
|
Product with packaging (kg)
|
15.32
|
|
|
|
|
|
|
Operating conditions
|
|
|
|
Temperature range (operation)
|
0°C to 40°C
|
Temperature range (storage)
|
-20°C to 60°C
|
Relative humidity
|
20%–80%
|
Altitude
|
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
|
MTBF (demonstrated)
|
70,000 hrs (excluded backlight)
|
|
|
|
|
|
|
Sustainability
|
|
|
|
Environmental and energy
|
PowerSensor, LightSensor, EnergyStar 7.0, RoHS, TCO Certified
|
Recyclable packaging material
|
100
|
Specific Substances
|
Mercury free, Lead free, PVC/BFR free housing
|
|
|
|
|
|
|
Compliance and standards
|
|
|
|
Regulatory Approvals
|
CE Mark, FCC Class B, EPA, cETLus, SEMKO, TUV-BAUART, TUV/ISO9241-307, UKRAINIAN, CU-EAC
|
EPEAT
|
TBC
|
|
|
|
|
|
|
Cabinet
|
|
|
|
Front bezel
|
Black
|
Rear cover
|
Black
|
Foot
|
Black
|
Finish
|
Texture
|
Cabinet Colour
|
Black
|
Cabinet Finishing
|
Texture
|
Bezel Type
|
3-sided frameless
|
|
|
|
|
|
|
What's in the box?
|
|
|
|
Monitor with stand
|
Yes
|
Cables
|
HDMI cable, DP cable, USB-C/A Y cable, Power cable
|
User Documentation
|
Yes
|
|
|
|
|
|
|
Marketing
|
|
|
|
Description
|
B Line Curved UltraWide LCD Monitor with USB-C
|
Market
|
Consumer
|
EAN
|
8712581760816
|
Model name
|
346B1C
|
Launch date
|
18-10-2019
|
Channel
|
B2B
|
|
|
|
|
|
|
USB docking
|
|
|
|
USB-C
|
Reversible plug connector
|
Super speed
|
Data and Video transfer
|
DP
|
Built-in Display Port Alt mode
|
USB-C power delivery
|
USB PD version 3.0
|
USB-C max. power delivery
|
Up to 90 W (5 V/3 A; 7 V/3 A; 9 V/3 A; 10 V/3 A;12 V/3 A; 15 V/3 A; 20 V/4.5 A)
|
|
|
|
|
|
|
Product Compatibility
|
|
|
|
Vesa Wallmount
|
100x100 mm
|
|
|
|
|
|
|
USB Connectivity
|
|
|
|
USB Type
|
USB-C/ USB 3.2
|
USB out ports
|
4
|
|
|
|
|
|
|
Connections
|
|
|
|
RJ45
|
Ethernet LAN (10 M/100 M/1 G)*
|
HDMI
|
1x
|
Displayport version
|
1.4
|
Displayport
|
1x
|
USB-C
|
USB 3.2 Type-C
|
|
|
|
|
|
|
Included accessories
|
|
|
|
USB Cable
|
USB Cable
|
