| Bezel : 9.9 mm (T/R/L), 14.4 mm (B) |
| Depth : 39.9 mm |
| 30% Tilting Installation |
| |
| |
| OVERVIEW |
| |
| |
 |
| |
| |
SUPERB PICTURE QUALITY
|
Clear View with Non-glare Coating
|
Viewers can be annoyed by unnecessary reflections when watching a screen under brightly lit conditions. The UH5F-H series has resolved such inconveniences by increasing the level of haze, which enhances visibility and text readability.
|
 |
| |
Native Resolution |
Brightness (Typ.) |
| |
3,840 x 2,160 (UHD) |
500 |
| |
|
|
| |
Contrast Ratio |
Dynamic CR |
| |
1,000:1 |
1,000,000 : 1 |
| |
|
*The luminosity ratio of Full Black / |
| |
|
Full White color on video input condition. |
| |
|
|
| |
Color gamut |
Viewing Angle (H x V) |
| |
BT709 95% |
178 x 178 |
| |
|
|
| |
Color Depth |
Response Time |
| |
1.07 Billion Colors (10 bit) |
8 ms (G to G) |
| |
|
|
| |
Surface Treatment (Haze) |
Operation Hours (Hours / Day) |
| |
Haze 28% |
24 / 7 |
| |
|
|
| |
Portrait / Landscape |
|
| |
Yes / Yes |
|
| |
|
|
|
|
|
| |
|
|
CONNECTIVITY
|
Input |
Output |
|
HDMI (2, HDCP 2.2/1.4), |
DP, |
| |
HDMI (1, HDCP 1.4), |
Audio |
| |
DP (1, HDCP 2.2/1.3), |
|
| |
DVI-D (HDCP 1.4), |
|
| |
Audio, |
|
| |
USB 2.0 Type A |
|
| |
|
|
| |
External Control |
|
| |
RS232C (4 Pin Phone Jack) In / Out, |
|
| |
RJ45(LAN) In, |
|
|
IR In |
|
| |
|
|
|
|
|
| |
|
|
MECHANICAL SPECIFICATION
|
Bezel Color |
Bezel Width |
| |
Black |
9.9mm(T/R/L), 14.4mm(B) |
| |
|
|
| |
Weight (Head) |
Monitor Dimension (W × H × D) |
| |
15.4 kg |
1,098.6 x 644.5 x 39.9 mm |
| |
|
|
| |
Monitor Dimensions with Stand (W × H × D) |
Handle |
| |
1,098.6 × 694.3 × 290.0 mm |
No |
| |
|
|
| |
VESA Standard Mount Interface |
|
| |
300 x 300 mm |
|
| |
|
|
|
|
|
| |
|
|
SPECIAL FEATURE
|
Tilt (Facedown) |
IP Rating |
| |
Yes (Max. 30?) |
IP5X |
| |
*In conditions within 30?C temperature, 50% humidity |
|
| |
|
|
|
|
|
| |
|
|
ENVIRONMENT CONDITIONS
|
Operation Temperature |
Operation Humidity |
| |
0°C to 40°C |
10% to 80% |
| |
|
|
|
|
|
| |
|
|
POWER
|
Power Supply |
Power Type |
| |
AC 100-240V~, |
Built-In Power |
| |
50/60Hz |
|
| |
|
|
|
|
|
| |
|
|
POWER CONSUMPTION
|
Typ. / Max. |
BTU (British Thermal Unit) |
|
95W / 130W |
324 BTU/Hr (Typ.), |
| |
|
444 BTU/Hr (Max.) |
| |
|
|
|
|
|
| |
|
|
SOUND
|
Speaker |
|
| |
Yes |
|
|
|
|
|
|
|
| |
|
|
CERTIFICATION
|
Safety |
EMC |
|
CB, NRTL |
FCC Class "A" / CE / KC |
| |
|
|
| |
ErP |
|
| |
Yes |
|
| |
|
|
|
|
|
| |
|
|
OPS COMPATIBILITY
|
OPS Type Compatible |
OPS Power Built In |
| |
Yes |
No |
| |
|
|
|
|
|
| |
|
|
SOFTWARE COMPATIBILITY
|
SuperSign CMS |
SuperSign Control / Control+ |
| |
Yes |
Yes |
| |
|
|
| |
SuperSign WB |
SuperSign Media Editor |
| |
Yes |
Yes |
|
|
|
| |
Signage365Care |
|
| |
Yes |
|
| |
(The availability can differ by region.) |
|
| |
|
|
|
|
|
| |
|
|
ACCESSORY
|
Basic |
Optional |
| |
Remote Controller, |
Stand (ST-653T), |
| |
Power Cord, |
Wall Bracket (LSW350B), |
| |
QSG, |
VESA Adapter (AM-B330S), |
| |
HDMI Cable, |
OPS Kit (KT-OPSF) |
| |
Regulation Book, |
|
| |
Phone to RS232C Gender |
|
| |
|
|
|
|
|
|
|
|
GENERAL
|
Region |
|
| |
Global |
|
SUPERB PICTURE QUALITY
|
With the resolution that is 4 times higher than FHD, it makes the color and details of the contents more vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents with no distortion.
|
